17Ew modela LCD-ê ya bilind, Brightness 1000 CD / M2 TFT LCD Screen, Sêwirana Bilind, Sêwirana Mezinahiya Nû, Saziya Nû ya Modulê ya Modulê û sazkirinê ya nû, belavkirina bilind, belavkirina germ û domdariya hêsan.
|
Size
|
17inch
|
|||
|
Panel item
|
RS170NET-N10
|
|||
|
Panel type
|
a-Si TFT-LCD
|
|||
|
Display mode
|
IPS,Normally black，transmissive display
|
|||
|
Pixels
|
1280*1024
|
|||
|
brightness
|
1000cd/m2
|
|||
|
Constrast Ratio
|
1000:1
|
|||
|
Response Time
|
3.8/1.2ms
|
|||
|
View angle
|
85/85/80/80
|
|||
|
View area
|
341.72*274.14mm(H*V)
|
|||
|
Dispaly area
|
337.92*270.336mm(H*V)
|
|||
|
Outline Size
|
358.5*296.5*10.8mm(H*V*D)
|
|||
|
Signal Type
|
LVDS
|
|||
|
Working freqyency
|
60Hz
|
|||
|
Working temperature
|
0- 50ﾟC
|
|||
|
Storage Temperature
|
-20 - +60ﾟC
|
|||
|
Display ratio
|
5:4
|
|||
|
Display color
|
16.7m
|
|||
|
Backlight Voltage
|
5V
|
|||
|
Backlight Power Consumption
|
8.4w
|
|||
|
Surface Treatment
|
Haze ,Hard coating(3H)
|
|||
|
Weight
|
1.27kgs
|
|||
