Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Şanika şewatê: Risingstar
Baikarhatinî: 500K
Cihê Origin: Shenzhen
Şehade: CE/ROSH/UL/SIO9001
800 NiTs LCD Module li Chinaînê, Module Mezinahiya 13.3inch, Ev Module Modulek Matrix LCD-ê rengîn e ku Oxide TFT (transistor Fîlimê ya Nerm) pêk tîne. Ew ji panelek TFT-LCD-ê rengîn, ajokar, ajokar, dorpêçê kontrolê û dorpêçê dravê kontrolê.Resulotion 1920 * 1080.
800nits Module Module bi resulotiyonê bilind re piştrast dike ku her hûrgulî dikare ji temaşevanan re were pêşkêş kirin, da ku agahdarî bi tevahî were veguhastin, û ev bandora dîtbar dikare temaşevanan bike.
13.3 inch Brightness LCD Module di wesayîtan de, nîşanên kontrola pîşesaziyê, kartên çîna elektronîkî, kartên nû yên bargiraniyê, hwd.
Bikaranînî:
| Size | 13.3inch |
| Panel item | RS133NET-N10 |
| Panel type | a-Si TFT-LCD |
| Display mode | IPS,Normally black，transmissive display |
| Pixels | 1920*1080 |
| brightness | 1000cd/m2 |
| Constrast Ratio | 800：1 |
| Response Time | 25ms |
| View angle | 89/89/89/89 |
| View area | 295.07*166.68mm(H*V) |
| Dispaly area | 293.472*165.078mm(H*V) |
| Outline Size | 309.7*184.1*10.1mm(H*V*D) |
| Signal Type | LVDS,30Pin |
| Working freqyency | 60Hz |
| Working temperature | 0- 70ﾟC |
| Storage Temperature | -25- +65.0ﾟC |
| Display ratio | 16:9 |
| Display color | 16.7m |
| Nominal Input Voltage | 3.3V |
| Surface Treatment | Haze |
| Weight | 0.5kgs |
