Şanika şewatê: Risinglcd
Baikarhatinî: 1250k
Cihê Origin: Shenzhen
Şehade: CE/ROSH/UL/ISO9001
Shenzhen Risingstar 10.1 inch 1000 Nit TFT Panel, Original Auo / Boe / Innolux LCD Module, girêdana sereke bi panelê LCD re bi navgîniya panelê bi navgîniya panelê ve girêdayî ye. Panelên cûda yên LCD formên navbeynê cûda bikar tînin. Risingstar 10.1 inch 1000 NiTs TFT LCD Panel bi piranî navgîniya lvds e.
Paremurer
| Size | 10.1inch |
| Panel item | RS101NET-N10 |
| Panel type | a-Si TFT-LCD |
| Display mode | IPS,Normally black，transmissive display |
| Pixels | 1280*800 |
| brightness | 350-1000cd/m2 |
| Constrast Ratio | 800:1 |
| Response Time | 14/11ms |
| View angle | 85/85/85/85 |
| View area | 218.96*137.6mm(H*V) |
| Dispaly area | 218.96*137.6mm(H*V) |
| Outline Size | 230.7*152.55*7mm(H*V*D) |
| Signal Type | LVDS |
| Working freqyency | 60Hz |
| Working temperature | -20~70ﾟC |
| Storage Temperature | -25~70ﾟC |
| Display ratio | 16:9 |
| Display color | 16.7m |
| Backlight Voltage | 3.3V |
| Backlight Power Consumption | 6.18w |
| Surface Treatment | Haze |
| Weight | 0.375kgs |
