Min. Emir:1 Piece/Pieces
Numreya Model: BA104S01-100
BA104S01-100 Hilbera Module ya 10.4-inch LCD-ê ye ku ji hêla Boe Technology Group Co., Ltd hatî destpêkirin. (Boe) teknolojiya A-Si TFT-LCD bikar tîne. Ew bi rengek paşde vekişandî ye, ne rêwîtiyek paşde û bê têkiliyek. BA104S01-100 Resolutionareserkirina 800 (RGB) × 600 (width: height) .1 Ji hêla Boe ve di 12-ê Decemberile, 2014 de hate berdan. Mezinahiya devera wê 211.2 × 158.4 × 5.9 (qelew) Mm, dermankirina erdê zelal e, giraniya netîceya hilberê 288g (Type.) Ye. VLAGE VLAGE PRODUCT A SOURE SOVAGEHA LSHIVE HEME 6S6P WLED bikar tîne, jiyana çavkaniya ronahiyê demjimêr 50k e, bêyî ajokerek paşde. BA104S01-100 LVDS (1 ch, 6/8/8-bit) navnîşa nîşana, bi giştî 20 zevî, girêdana termînalê dipejirîne, voltaja ekranê ya ajotinê 3.3V (Type.). Rêjeya nûvekirina vertical ya tîpîk FV 60Hz e. Ew li -20 ° C heta 70 ° C û firotgehên li -30 ° C li 80 ° C dixebite. Ev modela ji bo karanîna pîşesaziyê û bijîjkî ji ber ku li pişta xwe yê pîşesazî û bijîjkî tê pêşniyar kirin, zêdetirî 50,000 demjimêran, flipê termînal, 6/8 bîtên pîvanê yên bijare, û taybetmendiyên din ên bijare.
| brand | BOE | Model name | BA104S01-100 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 800(RGB)×600 [SVGA] 96PPI | Pixel configuration | RGB vertical bar |
| Display Area | 211.2×158.4 mm (H×V) | Surface treatment | Clear |
| Visual size | 215.0×162.0 mm (H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 236×176.9×5.9 mm (H×V×D) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
Ya jêrîn heman model û parameter hene
| brand | BOE | Model name | AV104X0M-N10 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | 215.4 × 161.8 (H×V) mm | Contrast Ratio | 1100:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 230 × 180.2(H×V) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -40 to 95 °C Operation Temperature: -30 to 85 °C |
| brand | BOE | Model name | TDA104-001V02 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 900cd/m²(Typ.)or customized | Outline dimension | 235×173×10.5mm(H×V×D) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -55 to 85 °C Operation Temperature: -40 to 80 °C |
Hot tags: Boe BA104S01-100 Brightness Panel-LCD, Chinaîn, Factory, Bihar, Dîmendal Dîmendera LCD-ê ji bo panel , LCD Panel, Modula LCD, nîşana ronahiya bilind.
