Taybetmendiyên Hilberê

Numreya Model: EV101WXM-N81

Packaging & Delivery

Yekîneyên firotanê:

Piece/Pieces

Danasîna Hilbera

EV101WXM-N81 modulek 10.1-inch lcd e ku teknolojiyek A-SI TFT-LCD bikar tîne. Ew bi paşpirtika paşîn ve hatî çêkirin, di nav de ajokera LED Driver Drive, bê têkilî. Resolution Display 1280 (RGB) × 800 (WXG), Rêjeya Aspectê ye 16:10 (Width: Height), û pixel di nav rêzikên vertical ên RGB de têne danîn. Mezinahiya devera wê ya 216.96 × 135.6 (× × Height) MM, mezinahiya dîtbar e 219.4 × bilind e (Type.). Di warê piştgiriyê de, ev hilber bi jiyanek 50k demjimêran re çavkaniyek ronahiya têketinê ya piştê bikar tîne, di nav de ajokarê LED. EV101WXM-N81 LVDS (1 ch, 8-bit) navgîniya nîşana bikar tîne, bi giştî 20 pin, girêdana termînalê bikar tîne, voltaja ekranê ya Drive 3.3V (Type.) Bikar tîne. Rêjeya nûvekirina vertical ya tîpîk FV 60Hz e. Ew li -20 ° C heta 70 ° C û firotgehên li -30 ° C li 80 ° C dixebite. Li ser bingeha paşiya xwe ya spî ya spî, jiyan ji 50,000 demjimêran zêdetir e.

R-Star ji Shenzhen, Chinaîn, em hilberînerek profesyonel LCD-ê ne, tevî modulên LCD LCD, tevî LCD-ê, Ultrathin LCD Highlight LCD, LCD-LCD-LCD, LCD-ya Pîşesaz, Ragihandî ya LCD-ê û Display Display, LCD-ya du-alî, LCD-ya du-alî ya LCD-ê û LCD-ya Duyemîn ya LCD-ya din. Bi kurtahî, zêdebûna ji 5 salan e ku hûn ji teknolojiya nû ya modulê ya modulê ya bilind a modulê bilind, 8 salan ji sêwirana Modulê ya TFT, Lêkolîn, Pêşveçûn, Kapasîteya hilberînê, 10 salan zincîra peydakirina materyalê ya bilind-kalîteyê.

brand	BOE	Model name	EV101WXM-N81
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800, WXGA, 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96×135.6(H×V)mm	Surface treatment	/
Visual size	233.2×152.9×10.4(H×V×D) mm	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	233.2×152.9×10.4(H×V×D)mm
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 20 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

Modela heman size û parameter wiha ne

brand	BOE	Model name	EV101WUM-N20
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1920(RGB)×1200, WUXGA, 224PPI	Pixel configuration	RGB vertical bar
Display Area	216.806×135.504mm(H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	600cd/m²(Typ.)or customized	Outline dimension	229.45×149.22(H×V)mm
Viewing Angle	80/80/80/80(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 45 pins
work environment	Storage temperature: -25 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	AT101WSM-N11-58P0
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×600, WSVGA, 117PPI	Pixel configuration	RGB vertical bar
Display Area	222.72×125.28mm(H×V)	Surface treatment	Fog surface，Hard coating (3H)
Visual size	226×128.6(H×V)mm	Contrast Ratio	500:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	235×144.9×5.44mm(H×V×D)
Viewing Angle	80/80/60/70(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 6/8-bit) , 60 pins , FPC
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	EV101WXM-N82
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800 [WXGA] 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96 × 135.6 mm (H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	228.6 ×149.2×6 mm (H×V×D)
Viewing Angle	85/85/85/85(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 40 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C
