Taybetmendiyên Hilberê

Numreya Model: TDA150-005V01

Packaging & Delivery

Yekîneyên firotanê:

Piece/Pieces

Danasîna Hilbera

TDA150-005V01 A-Si TFT-LCD 15-inch Lêkolîn Module, Taybetmendiyên tîpîk paşiya paşîn a spî ne, di nav de ajokarê LED, rûyê Matte. Germahiya wê ya xebitandinê -20 ~ 70 ° C, û germahiya wê ya hilanînê -30 ~ 80 ° C. Resolution Display 1600 (RGB) × 1200 (UXGA) ye, û pixel di nav rêzikên vertical ên RGB de têne danîn. Mezinahiya devera wê 304.8 × 228.6 (W × H) MM ye, û Dezgeha derveyî 317.4 (W) × 242 (H) MM ye.

Ew çavkaniyek ronahiyê ya tîrêjê ye ku bi tempilokek demjimêr 30k, di nav de ajokarên LED. TDA150-005V01 LVDS (2 ch, 8-bit) navnîşa îşaretê, bi giştî 40 pin, ku bi termînalan ve girêdayî ne, û voltaja ajotinê 3.3V e.).

15-2

Q: Em kî ne?

A: R-Star ji Shenzhen, Chinaîn, Em hilberînerek profesyonel LCD-ê ne, em dikarin ji modulên LCD-ê ya LCD-ê bilind bikin, em dikarin ji 100 karmendan bêtir peyda bikin, di nav de 20 endazyarên tecrûbe hene. Pargîdaniya ISO9001 / ISO14001 / CCC / ROHS / UL û sertîfîkayên din, xwedî platformek bilind-asta R & D, û bûye partnerê Pargîdaniyên Cîhan. Bazarên Asyayê, Bakur Amerîka, Afrîka, Rojhilata Navîn, Ewropa, Navendî û Başûr

Q: Hûn hilberîner in (fabrîk)?

A: Erê, em. Di heman demê de karûbarê OEM / OEM / ODM li vir peyda dibe. Kêfxweşiya me ye ku ji bo we çareseriya çêtirîn peyda dike.

Q: Em çawa dikarin kalîteyê garantî bikin?

A: Her gav çavdêriya paşîn berî barkirinê.

brand	BOE	Model name	TDA150-005V01
size	15 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1600(RGB)×1200 [UXGA] 133PPI	Pixel configuration	RGB vertical bar
Display Area	304.8×228.6mm (H×V)	Surface treatment	Fog surface(Haze 25%)，Hard coating (3H)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Contrast Ratio	1000:1 (Typ.) (TM)
Viewing Angle	85/85/85/85 (Min.)(CR≥10)	Outline dimension	317.4 × 242 mm (H×V)
Signal interface	LVDS (2 ch, 8-bit) ,erminal, 40 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

Heman pîvan û modela wiha ne:

brand	BOE	Model name	RT150X0M-N10
size	15 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×768, XGA, 85PPI	Pixel configuration	RGB vertical bar
Display Area	304.8×228.6mm (H×V)	Surface treatment	Fog surface(Haze 25%)，Hard coating (3H)
Brightness(cd/m²)	1100cd/m²(Typ.)or customized	Contrast Ratio	1000:1 (Typ.) (TM)
Viewing Angle	80/80/80/80 (Min.)(CR≥10)	Outline dimension	326.5×253.5(H×V)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 20 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	DV150X0M-N16
size	15 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×768, XGA, 85PPI	Pixel configuration	RGB vertical bar
Display Area	304.128×228.096(H×V) mm	Surface treatment	Fog surface(Haze 25%)，Hard coating (3H)
Brightness(cd/m²)	600cd/m²(Typ.)or customized	Contrast Ratio	1000:1 (Typ.) (TM)
Viewing Angle	89/89/89/89(Min.)(CR≥10)	Outline dimension	326.5×253.5×9.7mm(H×V×D)
Signal interface	20 pins LVDS (1 ch, 8-bit) , erminal
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	RV150U0M-N00
size	15 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1600(RGB)×1200 [UXGA] 133PPI	Pixel configuration	RGB vertical bar
Display Area	304.8 × 228.6 mm (H×V)	Surface treatment	Fog surface(Haze 25%)，Hard coating (3H)
Visual size	307.2 × 231 mm (H×V)	Contrast Ratio	1000:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	317.4×242 mm(H×V×D)
Viewing Angle	85/85/85/85(Min.)(CR≥10)
Signal interface	LVDS (2 ch, 8-bit),40 pins, erminal
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C
