Numreya Model: LA123WF1-SR03
Resolution Display La123WF1-SR03 (RGB) × 720 (RGB) × 720 e 8: 3 (Width: Height), û pixel di nav rêzikên vertical ên RGB de têne danîn. Mezinahiya qada dîmenê ya LA123WF1-SR03 e 292.032 × 109.512
[Pîşesaziya Pîşesaziya Pîşesaziya Pîşesaziyê ya Pîşesaziyê]
Rabûna star ji 10.1 "ji 100" ji 10.1 "û pêbaweriya bilind, bextewariya bilind, berxwedana hewayê ya bilind, panelên dirêj ên pîşesaziya pîşesaziyê jîngeh.
| brand | LG Display (LG Display) | Model name | LA123WF1-SR03 |
| size | 12.3 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution | 1920(RGB)×720 167PPI | Pixel configuration | RGB vertical bar |
| Display size | 292.032×109.512(H×V)mm | Surface treatment | Fog surface, Hard coating (3H) |
| Brightness(cd/m²) | 600 cd/m² (Min.) or customized | contrast | 800:1 (Min.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Appearance of size | 310×128×16.2mm(H×V×D) |
| Signal system | RSDS (2 Channel) , 110 pins , FPC |
|
|
| Maximum rated | Storage temperature: -40 ~ 95 °C Working temperature: -40 ~ 85 °C Vibration resistance: 3.0g (29.4m /s²) |
|
|
Tags Hot: 12.3inch La123WF1-SR03 LA123WF1-SR03 , 1000nits Square LCD Display , Panel LCD, Modela LCD, Dîmendera Brightness High.
