Numreya Model: LQ150X1LG96
Germahiya xebatê ya LQ150x1LG96 0 ~ 65 ° C e, û germahiya hilanînê -30 ~ 70 ° C. Ew ji bo serlêdanên pîşesazî, roniyên derveyî, lîstikan, lîstikan e. Tedawiya erdê Matte, Coating Hard (3H), û giraniya netîce ya hilberê 950g (Max.) Ye. Di warê piştê de, çavkaniya ronahiyê ya alîgirê demjimêrên 30k hene.
Resolution Display LQ150x1LG96 (RGB) × 768 (XGA) ye, rêjeya xalîçeyê 4: 3 (width: height), û pixel di nav rêzikên vertical ên RGB de têne danîn. Mezinahiya Qada Display ya LQ150x1LG96 e 304.128 × 228.096 (W × H) MM, û Mezinahiya Dîdarê 326.5 (W) × 10.5 (H) × 10.1 (D) mm.
| brand | Sharp | Model name | LQ150X1LG96 |
| size | 15inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 [XGA] 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 307.2×231.1mm(H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 1050cd/m²(Typ.)or customized | Outline dimension | 326.5×253.5×10.1 mm(H×V×D) |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) | work environment | Storage temperature: -30 to 70 °C Operation Temperature: 0 to 65 °C |
| Signal interface | LVDS (1 ch, 6/8-bit),erminal,20 pins |
|
|
| supply voltage | 3.3V (Typ.) |
|
|
Tags Hot: 15inch Sharp LQ150x1LG96 TFT LVDS Panel, Chinaîn, Factory, Bihar, Dîmender Panela LCD-ya li derve 2500 NiS , panelên LCD, Modela LCD, Display Brightness High.
